Chapter 9 Operational Settings
Appendix
Glossary
Introduction
Index
Contents
TOP
187
How to Load
Documents
Configuring the
Scan Settings
How to Use the
Operator Panel
Various Ways to
Scan
Daily Care
Troubleshooting
Replacing the
Consumables
Scanner
Overview
Operational
Settings
Shortening the Scanning Intervals [Pre-Pick]
"Pre-pick" refers to feeding the document to the starting
position for scanning before the next scan.
Enabling [Pre-Pick] shortens the interval between scanning
each document.
1 Start up the Software Operation Panel.
For details, refer to "9.1 Starting Up the Software Operation Panel"
(page 163).
2 From the listing on the left, select [Device Setting 2]
[Pre-Pick].
3 Select [Yes] or [No].
HINT
z If you cancel in the middle of scanning while pre-pick is
enabled, you will have to remove the pre-picked document,
then load the document again.
z This setting can also be configured in the scanner driver or the
operator panel. Note that priority is given to the scanner driver
setting.
