3-24
PRINTER
Contents
BLACK AND WHITE PRINTING
[Black and White] can be selected on the [Main] tab as well as on the [Color] tab. Click the [Black and White Print]
checkbox on the [Main] tab so that a checkmark appears.
The [Black and White Print] checkbox on the [Main] tab and the "Color Mode" setting on the [Color] tab are linked. When
the [Black and White Print] checkbox is selected on the [Main] tab, [Black and White] is also selected on the [Color]
tab.
(1) Select [Color].
(2) Select the "Color Mode" that you wish to
use.
Macintosh
(1)
(2)
