03/12/17 CD-SW200 _2-14.fm

11

CD-SW200

Preparation for Use

System connections

Left speaker Subwoofer

Right speaker

Speaker connection

(see page 12)

Antenna connection (see page 12)

AC power connection (see page 13)

AC Outlet

(AC 120 V, 60 Hz)

Make sure to unplug the AC power cord before any connections.

FM antenna

AM loop antenna
