– 23 –

MD-R3

Step 1 Testmode STOP state [ t s m e ]

Step 2

Press the ENTER button seventimes.

EEPROM setting menu [E E P R O M _ S E T]

Step 3 Press once the MD PLAY button. Focus setting menu [ _ _ F o c u s _ _ _ ]

Step 4 Press once the ENTER button. Focus system loop filter gain constant setting [ F G _ _ _ _ _ _ ]

Step 5 Press once the ENTER button. Focus system loop filter f characteristic constant 1 setting [ F F 1 _ _ _ _ _ ]

Step 6 Press once the ENTER button. Focus system loop filter f characteristic constant 2 setting [ F F 2 _ _ _ _ _ ]

Step 7 Press once the ENTER button. FZC oscillation histerisis level setting a [ F Z H L E V _ _ ]

Step 8 Press once the ENTER button. Comparison level setting (normal) in case of FOK generation [ F O K L E V n _ ]

Step 9 Press once the ENTER button. Comparison level setting in case of FOK generation [ F O K L E V f _ ]

(when focus is "ON")

Step 10 Press once the ENTER button. LPF coefficient setting (normal) in case of FOK generation [ F O K L P F n _ ]

Step 11 Press once the ENTER button. LPF coefficient setting in case of FOK generation [ F O K L P F f _ ]

(when focus is "ON")

Step 12 Press once the ENTER button. Waiting time setting in case of auto-focus retraction [ W A I T f_ _ _ ]

8. EEPROM setting mode

a) Focus setting

Step No.

Setting Method

Remarks Display

•

: Setting volue

• Pressing the REC button causes reversing.

• When the jog key is turned upward while the setting is displayed, the setting increases, and a new setting is stored in LSI.

• When the jog key is turned downward while the setting is displayed, the setting increases, and a new setting is stored in LSI.

Step 1 Testmode STOP state [ t s m e ]

Step 2

Press the ENTER button seven times.

EEPROM setting menu [E E P R O M _ S E T]

Step 3 Press once the MD PLAY button. Focus setting menu [ _ _ F o c u s _ _ _ ]

Step 4 Press once the ENTER button. Spindle setting menu [ _ S p i n d l e _ _ ]

Step 5 Press once the ENTER button. Spindle system loop filter gain constant setting [ S P G _ _ _ _ _ ]

(Until tracking servo ON)

Step 6 Press once the ENTER button. Spindle system loop filter gain constant setting [ S P G _ i n _ _ ]

(After tracking servo ON, inner periphery)

Step 7 Press once the ENTER button. Spindle system loop filter gain constant setting [ S P G _ m i d _ ]

(After tracking servo ON, center)

Step 8 Press once the ENTER button. Spindle system loop filter gain constant setting [ S P G _ o u t _ ]

(After tracking servo ON, outside periphery)

Step 9 Press once the ENTER button. Spindle system loop filter f characteristic constant 1 setting [ S P 1 _ _ _ _ _ ]

Step 10 Press once the ENTER button. Spindle system loop filter f characteristic constant 2 setting [ S P 2 _ _ _ _ _ ]

Step 11 Press once the ENTER button. Spindle system loop filter f characteristic constant 3 setting [ S P 3 _ _ _ _ _ ]

Step 12 Press once the ENTER button. Spindle system loop filter f characteristic constant 4 setting [ S P 4 _ _ _ _ _ ]

Step 13 Press once the ENTER button. Spindle system loop filter f characteristic constant 5 setting [ S P 5 _ _ _ _ _ ]

Step 14 Press once the ENTER button. Spindle drive output limitter setting [ S P D L I M _ _ ]

b) Spindle setting

Step No.

Setting Method

Remarks Display

•

: Setting volue

• Pressing the REC button causes reversing.

• When the jog key is turned upward while the setting is displayed, the setting increases, and a new setting is stored in LSI.

• When the jog key is turned downward while the setting is displayed, the setting increases, and a new setting is stored in LSI.

Step 1 Testmode STOP state [ t s m e ]

Step 2

Press the ENTER button seven times.

EEPROM setting menu [E E P R O M _ S E T]

Step 3 Press once the MD PLAY button. Focus setting menu [ _ _ F o c u s _ _ _ ]

Step 4

Press the ENTER button two times.

Tracking setting menu [ _ T r a c k i n g _ ]

Step 5 Press once the MD PLAY button. Tracking system loop filter gain constant setting [ T G _ _ _ _ _ _ ]

Step 6 Press once the ENTER button. Spindle system loop filter f characteristic constant 1 setting [ T F 1 _ _ _ _ _ ]

Step 7 Press once the ENTER button. Spindle system loop filter f characteristic constant 2 setting [ T F 2 _ _ _ _ _ ]

Step 8 Press once the ENTER button. Setting of tracking system servo mode 4 [ S V C N T 4 _ _ ]

Step 9 Press once the ENTER button. Tracking deceleration pulse level setting (for one line jump) [ T R B L V 0 _ _ ]

Step 10 Press once the ENTER button. Tracking deceleration pulse level setting (for 10 line jump) [ T R B L V t _ _ ]

c) Tracking setting

Step No.

Setting Method

Remarks Display

1 2 ... 18 19 20 21 22 23 24 25 26 27 28 ... 91 92
