01/3/1 XL-3000W(A)1.fm

General Information

- Controls and Indicators -

Controls and Indicators (continued)

„

Rear panel

Reference page

1. CD Digital Output Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

2. Cooling Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

3. Headphone Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

4. AM Aerial Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7, 8

5. Aerial Earth Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7, 8

6. FM 75 Ohms Aerial Socket . . . . . . . . . . . . . . . . . . . . . . . . 7, 8

7. Video/Auxiliary (Audio Signal) Input Sockets . . . . . . . . . . 24

8. AC Voltage Selector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7, 9

9. AC Power Input Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . 7, 9

10. Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7, 8

„

Speaker system

1. Tweeter

2. Woofer

3. Bass Reflex Duct

4. Speaker Terminals

Placing the speaker system:

There is no distinction between the right and the left speakers.

The rating label is located

on the bottom of the unit.

Speaker grilles are removable:

Make sure nothing comes into contact with the

speaker diaphragms when you remove the

speaker grilles.

Left speaker

Right speaker
