E-8

ENGLISH

XL-MP333H

XL-MP444H

04/5/26 XL-MP333H_MP444H_E.fm

TINSZA022SJZZ

Preparation for Use

Front speaker (left)Front speaker (right)Subwoofer

Wall socket

(AC 230 V, 50 Hz)

Speaker connection (see page 9)

FM aerial

Make sure to unplug the AC power lead before making any connections.

Aerial connection (see page 9)

(XL-MP444H)

Connecting the AC power lead (see page 10)

AM loop aerial
