Loading Printing Paper

Replace the received document tray.

• The received document tray must be

attached for the fax machine to operate

properly.

Loading paper in the paper cassette (if installed)

Note: To use A4 paper in the paper cassette, you must have a service

technician adjust the cassette.

Grasp the hand-hold on the cassette

and pull the cassette out until it stops.

Push the pressure plate down until it

locks into position.
