03/12/17 CD-SW200EA 02-12.fm

9

CD-SW200E

Preparation for Use

System connections

Left speaker Subwoofer

Right speaker

Speaker connection

(see page 10)

Aerial connection (see page 10)

AC power connection (see page 11)

Wall socket

(AC 230 - 240 V, 50 Hz)

Make sure to unplug the AC power lead before any connections.

FM aerial

AM loop aerial

Subwoofer

Light-up wire
