MD Playback

- Listening to a MiniDisc -

■ To locate the beginning of a track

To move to the beginning of the next track:

Press the

button for less than 0.5 seconds during playback.

● You can skip to any track by pressing the

button repeatedly until the de-

sired track number appears.

To restart the track being played:

Press the

button for less than 0.5 seconds during playback.

● You can skip to any track by pressing the

5 button repeatedly until the de-

sired track number appears.

■ To locate the desired portion

For audible fast forward:

Press and hold down the

button during playback.

For audible fast reverse:

Press and hold down the

button during playback.

Notes:

● Normal playback will resume when the

button is released.

● When the end of the last track is reached during fast forward, “END” will appear in

the display and MiniDisc operation will be paused. When the beginning of the first

track is reached during fast reverse or the

button is released, the unit will

enter the playback mode.

● The

5/3

2/4

button on the remote control allows you the same opera-

tions.

Listening to a MiniDisc (continued)

To interrupt playback:

Press the MD

button.

To resume playback from the same point, press the MD

button again.

To stop playback:

Press the MD ■ button.

To remove a MiniDisc:

Whilst in the stop mode, press the MD

button.

After use:

Press the ON/STAND-BY button to enter the power stand-by mode.

Caution:

● If TV or radio interference occurs during MiniDisc operation, move the unit away

from the TV or radio.

● Although MiniDiscs will not normally skip due to vibration, you may hear skipping

in the sound if there is continuous vibration.

If the volume is turned up too high, sound skipping may occur depending on the

contents of the MiniDisc.

If this happens, turn the volume down and the skipping should stop.

● If an error message is displayed during MiniDisc operation, see “Error Messages”

on page 45.

*MD9000H-E17-18 2001.4.20, 2:07 AM18
