- 21 -
MAC OS X
Macintosh
14
Configure the printer driver.
The procedure for configuring the printer driver varies depending on the operating system version. The
procedure for versions 10.4 - 10.4.10 and the procedure for other versions are explained separately below.
(1) Click the "Default Browser" icon.
If multiple AppleTalk zones are
displayed, select the zone that
includes the printer from the menu.
(2) Click the machine's model name.
• The machine's model name usually
appears as "SCxxxxxx". ("xxxxxx" is
a sequence of characters that varies
depending on your model.)
• The PPD file of the machine is
automatically selected.
(3) Make sure that the PPD file of your
model is selected.
(4) Click the "Add" button.
The PPD file of the machine is
automatically selected and the
peripheral devices installed on the
machine are detected and
automatically configured.
(1) Select "AppleTalk".
If multiple AppleTalk zones are
displayed, select the zone that
includes the printer from the menu.
(2) Click the machine's model name.
The machine's model name usually
appears as "SCxxxxxx". ("xxxxxx" is a
sequence of characters that varies
depending on your model.)
(3) Select the PPD file of the machine.
• If you are using Mac OS X v10.1.5,
select "Other". The PPD file selection
window will appear. Click "Startup
disk name" - "Library" - "Printers" -
"PPDs" - "Contents" - "Resources" -
"en.lproj" - "PPD file for your model",
and then click the "Choose" button.
• If you are using Mac OS X v10.2.8,
select "Sharp" and click the PPD file
of your model.
• If you are using Mac OS X v10.3.9,
select "Auto Select".
(4) Click the "Add" button.
If you are using Mac OS X v10.3.9, the
PPD file of the machine is automatically
selected and the peripheral devices
installed on the machine are detected
and automatically configured.
If you are using Mac OS X v10.1.5, this completes the configuration of the printer driver. If you
are using a version other than Mac OS X v10.1.5, go to the next step.
v10.4 - 10.4.10
(1)
(2)
(4)
(3)
10.1.5, v10.2.8, v10.3.9
(1)
(2)
(4)
(3)
The PPD file is installed in the following folders on the startup disk.
"Library" - "Printers" - "PPDs" - "Contents" - "Resources" - "en.lproj"
Note
