MODEL: AR-5516NAR-5520NDIGITAL MULTIFUNCTIONAL SYSTEMOPERATION GUIDE

8POWER ON AND OFFThe power switch is located on the left side of the machine.POWER ONTurn the power switch to the "ON" position.It will take

98REPLACING THE TONER CARTRIDGEWhen the toner cartridge replacement required indicator ( ) lights up, the toner cartridge will need replacement soon.

997Chapter 7ROUTINE MAINTENANCEThis chapter explains how to keep the machine operating smoothly, including viewing copy count/scan count/the toner lev

100ROUTINE MAINTENANCECHECKING THE TONER LEVELThe toner level is indicated by a 6-level display. Use it as a guideline for replacing the toner cartrid

1017ROUTINE MAINTENANCECLEANING THE DOCUMENT GLASS AND RSPF/DOCUMENT COVERIf the document glass, underside of the document cover/RSPF, or the scanner

102ROUTINE MAINTENANCECLEANING THE BYPASS TRAY PAPER FEED ROLLERIf misfeeds occur frequently when feeding envelopes, thick paper, etc. through the byp

1037HOW TO MANUALLY RESET THE NETWORK SETTINGS OF THE MACHINETurn off the machine's power switch.Turn on the power while holding down the push sw

1048Chapter 8PERIPHERAL DEVICES AND SUPPLIESOptional equipment and supplies are explained in this chapter. To purchase optional equipment and supplies

105PERIPHERAL DEVICES AND SUPPLIES8REVERSING SINGLE PASS FEEDERFor the names of the parts of the RSPF, see "PART NAMES AND FUNCTIONS" (p.4).

106STORAGE OF SUPPLIESStandard supplies for this product that are to be replaced by the user are paper and toner cartridge.PROPER STORAGE● Store the s

OPERATION GUIDEAR5520N-GB2

91LOADING PAPERThe paper required indicator ( ) will light up when there is no copy paper in the selected paper feed tray, or when the selected pape

10BEFORE USING THE MACHINELOADING PAPERMake sure that the machine is not copying or printing, and then follow these steps to load paper.Loading the pa

11BEFORE USING THE MACHINE1Loading the bypass tray1Unfold the bypass tray.When feeding large paper such as B4 and A3, pull out the bypass tray extensi

12BEFORE USING THE MACHINEEnvelopesDo not use the following envelopes, as misfeeds will occur.• Envelopes with metal tabs, clasps, strings, holes, or

13BEFORE USING THE MACHINE13Use the [ORIGINAL] key () to select the paper size.The indicator of the selected paper size lights up.Changing bypass tray

14OPERATION IN COPY, PRINTER, AND SCANNER MODESSome operations cannot be performed simultaneously when the machine is being used in printer mode, copy

152Chapter 2COPY FUNCTIONSThis chapter explains how to use the copy functions.NORMAL COPYINGThis section explains how to make a regular copy.If "

16COPY FUNCTIONSCopying from the RSPF1Make sure that an original has not been left on the document glass. Close the RSPF.2Adjust the original guides t

17COPY FUNCTIONS2Auto paper select mode (when there are two or more paper trays)When the AUTO PAPER SELECT indicator ( ) lights up, "Auto paper s

18COPY FUNCTIONSMAKING A COPY DARKER OR LIGHTERAutomatic exposure adjustment is initially enabled. This function automatically adjusts the copy image

19COPY FUNCTIONS2SETTING THE NUMBER OF COPIESPress the numeric keys to set the number of copies.●The set number of copies appears in the display. A ma

20COPY FUNCTIONS4Press the [AUTO IMAGE] key ( ).The AUTO IMAGE indicator ( ) lights up and the appropriate ratio for the original size and paper size

21COPY FUNCTIONS2SELECTING THE VERTICAL AND HORIZONTAL COPY RATIOS SEPARATELY (XY ZOOM Copying)The XY ZOOM feature allows the horizontal and vertical

22COPY FUNCTIONS6Use the [PRESET RATIO] selector keys ( , ) and [Zoom] keys ( , ) to change the copy ratio in the horizontal direction.Press the [PRE

232AUTOMATIC TWO-SIDED COPYINGTwo originals placed on the document glass can be copied onto each side of a single sheet of paper. In addition, an RSPF

24COPY FUNCTIONSUsing the document glass1Place the original that you wish to copy onto the front side of the paper on the document glass and close the

25COPY FUNCTIONS2IMAGE ROTATION IN DUPLEX COPYINGThis function is used to invert the top and bottom of the image on the front side of the paper during

26TWO-SIDED COPYING USING THE BYPASS TRAYTo perform manual two-sided copying, follow these steps.Example: Copying originals A and B onto each side of

272DUAL PAGE COPYINGA dual page original can be automatically separated into two pages during copying. This feature is convenient for making copies of

1CONTENTS1 BEFORE USING THE MACHINEPART NAMES AND FUNCTIONS ... 4● OPERATION PANEL ...6POWER ON

28INTERRUPTING A COPY RUN (Interrupt Copying)A copy run can be temporarily interrupted to allow another copy job to be performed. When the other job i

292CONVENIENT COPY FUNCTIONSThis section explains major convenient copy functions.ROTATING THE IMAGE 90 DEGREES (Rotation Copy)When "Auto paper s

30COPY FUNCTIONSUsing the document glass1Place the first original. (p.15)2Select the original size. (p.15)3Press the [SORT/GROUP] key ( / ) to select

31COPY FUNCTIONS2COPYING MULTIPLE ORIGINALS ONTO A SINGLE SHEET OF PAPER (2 IN 1 / 4 IN 1 Copy)Multiple originals can be copied onto a single sheet of

32COPY FUNCTIONSUsing the RSPF1Place the originals. (p.16)2Press the [2 IN 1 / 4 IN 1] key ( / ) to select the mode.The mode is selected in the order

33COPY FUNCTIONS2CREATING MARGINS WHEN COPYING (Margin Shift)The MARGIN SHIFT feature, in its initial setting, automatically shifts the text or image

34COPY FUNCTIONSERASING SHADOWS AROUND THE EDGES OF A COPY (Erase Copy)● This feature is used to erase shadows that appear around the edges of copies

353Chapter 3PRINTER FUNCTIONSThis chapter explains how to use the printer functions.The procedure for loading paper is the same as for loading copy pa

36PRINTER FUNCTIONSIf the tray runs out of paper during printingAdd paper to the tray or press the [PAPER SELECT] key ( ) to select a different tray,

373PRINTER DRIVER SETTING SCREENSome restrictions exist on the combinations of settings that can be selected in the printer driver setup screen. When
