SADDLE STITCH FINISHER
3-11
3
10
Open the front cover.
11
Turn roller rotating knob in the direction of
the arrow.
12
Remove any misfed paper from the saddle
stitch tray.
Be careful not to tear the
misfed paper during
removal.
13
Close the saddle stitch section cover.
14
Close the front cover.
15
Push the saddle stitch finisher back
against the main unit.
