0-2

Improper installation may damage this product. Please note the following during initial installation and whenever the

machine is moved.

1.The machine should be installed near an

accessible power outlet for easy connection.

2.Be sure to connect the power cord only to a

power outlet that meets the specified voltage and

current requirements. Also make certain the

outlet is properly grounded.

●For the power supply requirements, see the

name plate on the back of the main unit.

3.Do not install your machine in areas that are:

●damp, humid, or very dusty

●exposed to direct sunlight

●poorly ventilated

●subject to extreme temperature or humidity

changes, e.g., near an air conditioner or

heater.

4.Be sure to allow the required space around the

machine for servicing and proper ventilation.

A small amount of ozone is produced within the machine during operation. The emission level is insufficient to

cause any health hazard.

NOTE:

The present recommended long term exposure limit for ozone is 0.1 ppm (0.2 mg/m

) calculated as an 8 hr. time-

weighted average concentration.

However, since the small amount that is emitted may have an objectionable odor, it is advisable to place the copier

in a ventilated area.

60cm

(23-5/8")

80cm

(31-1/2")

30cm (11-13/16")

60cm (23-5/8")

INSTALLATION REQUIREMENTS
