Batch Transmission
114
♦ If no documents have been stored under a Batch Key when the time
for transmission arrives, transmission will not take place.
1
Load the document (s).
• SEND READY will appear in the
display.
2
Press the appropriate Batch Key.
• After scanning, the message
number assigned to your document
will appear in the display.
3
Press the STOP key.
• The document will be transmitted
at the designated time along with
any other jobs stored under the
same key. After transmission, all
jobs in the batch will be cleared
from memory.
(Example)
CLEARSPSHIFTSPACE
A
I
Q
Y
B
J
R
Z
C
K
S
D
L
T
E
M
U
F
N
V
G
O
W
H
P
X
01
09
17
25
02
10
18
26
03
11
19
04
12
20
05
13
21
06
14
22
07
15
23
08
16
24
27 28 29 30 31 32
STOP
all-FO4700.book Page 114 Tuesday, November 28, 2000 2:07 PM
