Timer Operations
81
5. Special
Functions
12 Press and/or to adjust the resolution and contrast if
desired, and then press .
13 Load the document and then press .
• The document will be scanned into memory.
RESOLUTION
CONTRAST
START/
ENTER
START/
ENTER
Polling
(Continued from Initial procedure.)
8 Dial the machine to be polled using one of the following methods:
• Press a Rapid Key.
• Press and enter a Speed Dial number (if you enter less than 2
digits, press to complete the entry).
• Enter a full fax number with the numeric keys.
9 Press .
SPEED DIAL
START/
ENTER
START/
ENTER
Serial Polling
(Continued from Initial procedure.)
8 Dial the machines to be polled using one or more of the following
methods:
• Press one or more Rapid Keys.
