REDUCING OR ENLARGING A COPY

There are three ways to enlarge and reduce copies:

• Automatic selection of a ratio according to the paper size: Auto ratio selection

• Specifying a ratio from 25% to 400%: Preset ratios/zoom

• Selecting the vertical and horizontal ratios separately: XY zoom

AUTOMATIC RATIO SELECTION

Place the original in the document

feeder tray or on the document glass.

The original size will appear in the display. If the

correct size does not appear, see "SELECTING THE

ORIGINAL SIZE" (p.35).

Press the [PAPER SELECT] key to

select the desired tray.

If the bypass tray is selected,

automatic ratio selection cannot

be used.

Press the [AUTO IMAGE] key.

• The copy ratio will be automatically set.

•

If the original and paper are in different orientations,

the image is automatically rotated to match the paper

orientation (rotation copy). However, if enlargement is

selected for copying onto a paper size larger than A4

(8-1/2" x 11"), the image will not be rotated.

• Rotation of the image can be disabled in the system

settings when reducing or enlarging a original.

(p.122)

• If the message "Image edge loss." is displayed, part

of the original image may be cut off.

Set the number of copies and press

the [START] key ( ).

• To cancel automatic ratio selection, press the [AUTO

IMAGE] key again.

• When copying from the SPF/RSPF, automatic ratio

selection mode will automatically disable after the

[START] key is pressed and the original is scanned.

When the SPF/RSPF is being used, the zoom copy ratio range is 50% to 200%.

Note

Automatic ratio selection can be used when

the original size is , A3, B4, A4, A4R, A5,

11" x 17", 8-1/2" x 14", 8-1/2" x 13", 8-1/2" x

11", 8-1/2" x 11"R and 5-1/2" x 8-1/2". It

cannot be used for other sizes.

Note
