XC810 style CTG. RECONDITIONING

XC-810 style Toner/Developer Cartridges:

XC-810/811/820/820/822/830/840/855/865/876,

XC-1020/33/40/44/45, XC-1245/50/55

Also: Sharp Z-810/820/830/835/845, SF-1010/1012/1112

Available Parts: (see p.129)

Refill Toner & Developer

Information:

Full Instructional: free on our Website

Related Status Codes:

Dry Ink Cartridge Indicator light on (calls for new or refilled cartridge)

Capacity: Holds 170g. of Toner, 180g. of Developer

Yield: 4,000 copies assuming copies of regular text (5% coverage)

OEM “Reorder #’s” 6R881(US), 6R890(RX)

Basic Procedure: (full instructional on our Website)

 Remove the front Toner Reclaim Box & empty it out.

 Remove the cover behind the Reclaim Box.

 Remove large plug from the Toner Fill Hole.

 Replace the developer on the mag-roll if needed… brush off old

developer… DON’T USE A VACUUM or forced air (there’s a toner

sensor inside which is easily blown by static discharge) and pour new

developer directly on the mag roller, turning it in as you go.

 Use a funnel to pour in new toner.

 Reassemble.

Toner Light Reset:

Automatic… When powered up, the machine will stir the toner to tone-up the

developer & sense when it’s ready. You may need to turn the machine off &

back on a second time if the toner light returns at first… (this happens

sometimes with fresh developer & even with new ctgs.)

Important Notes:

The difference between these cartridges & the Sharp® Z-810, etc. version is a

physical one. The large oval shaped indexing shaft on the rear of the cartridge

is positioned about ¼” differently between the two makes of cartridge.

The Parts Drop (201)387-7776 ... www.partsdrop.com

p.133
