SCANNER FUNCTIONS
95
Storing scanning settings - Scan to USB
Sets of scan settings (color mode, resolution, file type, etc.) can be stored for use in
various scanning applications. Each set of settings is called a "Scan Mode". When
storing a destination, you can select one of the stored scanned modes. The settings
of the selected scan mode will be used when you scan an image and send it to that
destination (p.99 to p.105) including Scan to USB.
1
Click "Scan to USB" in the menu
frame of the Web page.
2
Select the desired scanning settings.
Refer to the following table for information on each setting.
3
When you have finished selecting the settings, click "Submit".
The selected settings are stored.
