CHAPTER5
COPIER TROUBLE? Misfeed removal
MISFEED REMOVAL
7
Close the front cover.
Misfeed in the paper trays
1
Open the right side covers.
●
Grasp the handle and gently open the cover.
2
Remove the misfed paper.
●
Be careful not to tear the misfed paper during removal.
3
If the paper cannot be seen from the side, pull out the
paper tray which was in use and remove the misfed
paper.
●
Be careful not to tear the misfed paper during removal.
MISFEED HAS OCCURRED.
CLEAR INDICATED AREA.
PRESS FOR RECOVERY INSTRUCTIONS.
