NETWORK EXPANSION KITOPERATION MANUAL(for network printer)MODELAR-NB3Page•INTRODUCTION ...1•CONTENTS...2•PRI

9PRINTING FROM WINDOWS1Pamphlet stylePamphlet style prints two pages each on the front and back of each sheet of paper (four pages total on one sheet)

10PRINTING FROM WINDOWSPRINTING MULTIPLE PAGES ON ONE PAGEThis feature allows you to reduce and print two, four, six, eight, nine or sixteen document

11PRINTING FROM WINDOWS1FITTING THE PRINT IMAGE TO THE PAPERThe printer driver can adjust the size of the print image to match the size of the paper l

12PRINTING FROM WINDOWSROTATING THE PRINT IMAGE 180 DEGREESThe print image can be rotated 180 degrees.This feature rotates the print image 180 degrees

13PRINTING FROM WINDOWS1PRINTING TEXT AND LINES IN BLACKColor text and lines that are normally printed in light color can be printed in black. Color t

142PRINTER UTILITIES (WINDOWS)This chapter explains printer utilities that are used to manage and monitor the network printer.PRINTER UTILITIESThe &qu

152USING THE PRINTER UTILITIESSTARTING UP THE PRINTER UTILITIESIf the Printer Status Monitor or Printer Administration Utility is not running, use the

16PRINTER UTILITIES (WINDOWS)CHECKING THE PRINTER STATUSThe Printer Status Monitor allows you to check whether or not toner and paper remain in the ma

173PRINTING FROM A MACINTOSHThis chapter explains the procedures for printing from a Macintosh environment.BASIC PRINTINGTo use the machine as a print

18PRINTING FROM A MACINTOSH5Select print settings.Click next to [Copies & Pages] ([General] in Mac OS 8.6 to 9.2.2) and select the settings that

1INTRODUCTIONThe optional network expansion kit (AR-NB3) enables the machine to be used as a network printer.Note• This manual only explains the netwo

19PRINTING FROM A MACINTOSH3WHEN [PAPER FEED] IS SET TO [AUTO SELECT]If [Paper Feed] is set to [Auto Select] in the Print window and the correct size

204WEB FUNCTIONS OF THE MACHINEThe network expansion kit includes a built-in Web server. The Web server is accessed using a Web browser on your comput

214ABOUT THE WEB PAGES (FOR USERS)When you access the user Web pages in the machine, the following page will appear in your browser.A menu frame appea

22WEB FUNCTIONS OF THE MACHINEDIRECTLY PRINTING A FILE ON A COMPUTERA file that can be accessed by your computer can be directly printed without using

23WEB FUNCTIONS OF THE MACHINE4PRINTER DEFAULT SETTINGSConfigure basic printer settings and printer language settings. The printer default settings co

24WEB FUNCTIONS OF THE MACHINEPrinter condition settingsFactory default settings are indicated in bold.Default settingsPCL settingsPostScript settings

254ABOUT THE WEB PAGES (FOR THE ADMINISTRATOR)In addition to the menus that appear for users, other menus that can only be used by the administrator a

26WEB FUNCTIONS OF THE MACHINEPROTECTING INFORMATION PROGRAMMED IN THE WEB PAGE ([PASSWORDS])Passwords can be set (click [Passwords] in the menu frame

27WEB FUNCTIONS OF THE MACHINE4E-MAIL PRINT FUNCTIONAn e-mail account can be set up for the machine. When this is done, the machine will periodically

28WEB FUNCTIONS OF THE MACHINEKEY OPERATOR PROGRAMSThe key operator programs are used to prohibit changes to the [Condition Settings] and to configure

2CONTENTSINTRODUCTION ...

29WEB FUNCTIONS OF THE MACHINE4E-MAIL STATUS AND E-MAIL ALERT SETTINGSThese functions send information on machine use (print count, copy count, etc.)

30WEB FUNCTIONS OF THE MACHINEStatus message setupUse the status message function to send the current counter information, including the copy count, p

315KEY OPERATOR PROGRAMSThe key operator programs allow the administrator of the machine (key operator) to enable and disable functions to suit the ne

32USING THE KEY OPERATOR PROGRAMSBASIC PROCEDURE FOR CONFIGURING SETTINGSFollow the steps below to access the key operator settings for the network an

33KEY OPERATOR PROGRAMS5SPECIAL SETTINGSIP address settingsThis program is used to set the "IP ADDRESS", "SUBNETMASK", and "D

346TROUBLESHOOTINGTROUBLESHOOTINGThis chapter explains what to do when the machine does not connect to the network or when problems occur during print

35TROUBLESHOOTING6Problems during printingProblem Cause and solution PageThe machine does not receive print data. (The DATA indicator does not blink.)

36TROUBLESHOOTINGA notice page is printedIf you find that a notice page has been printed at the end of a print job, the print data received from the c

376CHECKING THE IP ADDRESS There are several settings where the IP address must be entered or checked. To check the IP address of the machine, hold do

387SPECIFICATIONSPRINTER SPECIFICATIONS*1 Print speed during printing of the second sheet and following sheets when using 8-1/2" x 11" (A4)

31PRINTING FROM WINDOWSThis chapter explains the basic procedure for printing in Windows and how to select printer driver settings. BASIC PRINTINGThe

397PRINTER DRIVER SPECIFICATIONS*1 N-up printing cannot be used in Windows NT 4.0. In Windows 2000/XP/Server 2003, 2, 4, 6, 9, and 16 N-up printing ca

AR-NB3 (for network printer)SHARP CORPORATION ARNB3-EN-PRINTER
