118

SENDING TWO PAGES AS A SINGLE PAGE

(2in1)

Two original pages can be reduced to half their original size and sent together as a single page.

Place the original(s).

• The 2in1 function cannot be used when the originals are larger than A4 (8-1/2" x 11") size.

• When placing the originals, orient them as explained below.

1 2

Portrait-oriented originals

Landscape-oriented originals

Transmission

1 2

Document feeder tray

Place the original face up.

Portrait orientation

Landscape orientation

Document glass

Place the originals face down.

Originals
