5 Clean the air filter.

• Clean the dust off the air filter and

cover with a vacuum cleaner extension

hose.

6 Replace the air filter.

• Place the air filter underneath the tabs

on the filter cover.

7 Replace the filter cover.

• Slide the filter cover in the direction of

the arrow to close it.

Note

• Be sure the filter cover is securely

installed. The power will not turn on

unless it is correctly installed.

• If dust or dirt has collected inside the

bottom air filter (not removable), clean the

filter with a vacuum cleaner extension

hose.

Replacing the Air Filter

-82
