3EN
Recording Disc Playback EditingBefore you start Connections Getting started
Changing the
Setup menu
OthersVCR functions
Before you start
Precautions (cont’d)
Copyright
Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby
Laboratories.
Dolby Digital Recording
“Dolby® Digital Recording enables consumers to record high-quality video with stereo sound on recordable DVD
discs. The technology, when utilized instead of PCM recording, also saves recordable disc space, allowing for higher
video resolution or extended recording time on each DVD. DVDs created using Dolby Digital Recording will play
back on all DVD-Video players.”
Note: This is true when the players are compatible with actual recordable DVD discs.
“DTS” and “DTS Digital Out” are trademarks of Digital Theater Systems, Inc.
“Kodak Picture CD COMPATIBLE” is a trademark of Eastman Kodak Company.
is a trademark of DVD Format/Logo Licensing Corporation.
DivX, DivX Certified, and associated logos are trademarks of DivX, Inc. and are used under license.
Copyright may exist in material you wish to record. Copying such material without permission of the relevant licensee(s) or
owner(s) of the copyright is prohibited by law. SHARP is not in a position to authorise the recording of copyright works and
nothing in this manual should be read or implied as giving that authority.
Copy Protection
This unit supports Macrovision copy protection.
On DVD discs that include a copy protection code, if the contents of the DVD disc are copied using a VCR, the copy
protection code prevents the videotape copy from playing normally.
U.S. Patent Nos. 4,631,603; 4,819,098; 4,907,093; 5,315,448; and 6,516,132.
This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual
property rights. Use of this copyright protection technology must be authorised by Macrovision, and is intended
for home and other limited viewing uses only unless otherwise authorised by Macrovision. Reverse engineering or
disassembly is prohibited.
Location and Handling
When attempting to record copy protected material on a VCR or other recording device, the copy protection will
activate and the protected material will not be recorded correctly. In addition, attempting to display copy protected
material on a monitor connected via a VCR, whether for the purpose of viewing or not, will cause an inferior quality
picture to be displayed. This is not a fault of the equipment. Please view copy protected material by connecting the
product directly to the monitor.
Do not stand the unit vertically. Install the unit in a horizontal and stable position. Do not place anything directly on top
of the unit. Do not place the unit directly on top of the TV.
Depending on the TV, noise or disturbance of the picture and/or sound may be generated if the unit is placed too close
to your TV. In this case, please ensure enough space between your TV and the unit.
Do not cover or place the unit in enclosed spaces to prevent excessive temperature build up.
Keep the distances 20cm around apparatus of ventilation openings.
Do not place the unit in direct sunlight, or near heat sources. Do not place any combustible objects on the device (candles, etc.).
Depending on the environment, the temperature of the unit may increase slightly. This is not a malfunction.
Keep the unit away from strong magnetic objects.
Do not place any object containing water or other liquids on the unit. In the event that liquid should enter the cabinet,
unplug the unit immediately and contact the retailer or service centre approved by SHARP immediately.
Do not remove the unit cabinet. Touching parts inside the cabinet could result in electric shock and/or damage to the
unit. For service and adjustment inside the cabinet, call a qualified dealer or service centre approved by SHARP.
Be sure to remove a disc and unplug the AC power cord from the output before carrying the unit.
Disconnect the mains plug to shut off when find troubles or not in use.
The mains plug shall remain readily operable.
Read both manual instructions to ensure correct and safe installation and interconnection of the unit in multimedia systems.
