FO785A-MAMA

For Australia

For New Zealand

<P=001>

Chapter

Maintenance

Fax print head

Clean the printing head frequently to assure optimum printing

performance.

First unplug the telephone line, then unplug the power cord.

Pull the paper release plate forward and remove the paper.

Open the operation panel (grasp the finger hold and pull up), and

then pull the release on the right side of the machine forward to open

the print compartment cover.

106
