Remote Operations
57
2. Answering
Machine
2
When you hear a short beep, speak
into the telephone to record the new
message.
• The message can be up to 15
seconds long. After 15 seconds (or
earlier if the machine detects
silence after you finish speaking),
you will hear a beep, and the new
message will be played back.
Turning the Transfer function on or off
To turn Transfer on: Press "9", "1",
and "#" on the telephone.
To turn Transfer off: Press "9", "2",
and "#" on the telephone.
1
(Example)
9
Changing the transfer telephone number
1
Press "9", "0", and "#" on the
telephone.
9 0
2
After you hear a short beep, enter the
new telephone number. When
finished, press "#".
• To insert a pause between any two
digits of the number, press "*".
5
6 314 1 4
(Example)
