6

Pull the empty spool toward the back of

the compartment, unwinding the film as

you pull.

7

Insert the empty spool into the back of

the compartment so that the gear and the

flange fit into the slots on the sides of the

compartment.

• Make sure that the gear engages with

the gear below it.

8

Wind the film slightly (rotate the gear on

the right side of the empty spool) so that

there is no slack in the film. Make sure

that both edges of the film wind onto the

spool evenly.

Chapter 1 Installation

4
