Optional Answering Machine Settings
43
2. Answering
Machine
Optional Answering Machine Settings
Setting ICM time
Incoming messages (ICMs) are the messages which callers leave for
you on the built-in answering machine. The answering machine is set
at the factory to allow each caller a maximum of 4 minutes to leave a
message. If desired, you can change this setting to 15, 30, or 60
seconds.
1
Press these keys:
The display will show:
0
A.M. SETTINGS
2
Press these keys:
The display will show:
ICM RECORD TIME
3
Press a numeric key to select the
desired ICM recording time:
• 1: 15 seconds
• 2: 30 seconds
• 3: 60 seconds
• 4: 4 minutes
1
3
2
4
4
Press the STOP key.
FUNCTION
STOP
