ENGLISH

Supplied Components

Preparing the Remote Control Unit and the Touch Pen

Installing the batteries

1. Press the cover gently and slide it in the direction of the

arrow.

2. See the instructions in the compartment and put in the

suppliedbatteries(R-6(“AA”size)x2)withtheirplus(+)

andminus(-)sidesorientedcorrectly.

3. Closethecover.

Inserting the battery

1. Rotate the battery cap and remove it, and then pull out the

cover.

Battery cap

2. Insertthesuppliedbattery(LR-03(“AAA”size))inthe

orientation shown, and attach the cover and battery cap.

If any component should be missing, please contact your dealer.



LiquidCrystalDisplayMonitor:1



Remote control unit: 1



Cableclamp:3



Power cord: 1



R-6battery(“AA”size):2



CD-ROM(UtilityDiskforWindows):1



Setup Manual (this manual): 1

* SharpCorporationholdsauthorshiprightstotheUtilityDiskprogram.Donotreproduceitwithoutpermission.

* For environmental protection!

 Donotdisposeofbatteriesinhouseholdwaste.Followthedisposalinstructionsforyourarea.



Touch pen: 1



Pen tip (for touch pen): 2



Touch pen battery

(LR-03(“AAA”size)):1



USBcable:1



Eraser: 1



Tray: 1



Traymountingtting(cover/bracket):x2



Traymountingscrews:M5x4/M4x2



Terminal label: 1

Used when installing the expansion board

PN-ZB01(optional).



CoverSharplogo:1

Place this sticker onto the SHARP logo to

cover the logo.
