ThermaCAM
®
B400
INFRARED CAMERA
Camera includes:
Transport case
Camera lens cap
Battery
2-bay battery charger, incl. power supply with local plug
Headset, 3.5 mm plug
Video Cable
USB cable Std A <-> Mini B, 2 m/6.6 ft.
SD Memory Card
Sun Shield
Stylus Pen
CD-ROM documentation
Operators Manual, Quick reference guide
I
nterchangeable lenses (optional)
Optional Add-on optics,Telephoto lens, 15°
Optional Add-on optics,Wide angle lens, 45°
1 800 464 6372
CANADA: 1 800 613 0507
www.goinfrared.com/B400
Specifications subject to change. ©Copyright 2007, FLIR Systems,Inc. All rights reserved. I071307PL
ThermaCAM® B400 Technical Specifications
I
maging Performance
Field of view/min focus distance 25
º
x18.8
º
/ 0.4 m (1.31 ft.)
Thermal sensitivity (N.E.T.D) < 0.07°C (< 0.14°F) @ +30°C (+86°F)
Detector type Focal Plane Array (FPA), uncooled microbolometer
Spectral range 7.5 to 13 µm
Digital zoom 1-8X continuous
Spot size ratio (with 15° lens) 1.4 mRad
I
mage Presentation
Image modes Thermal/Visual, Simultaneous,Video, Fusion
Display Built-in display, 3.5 in. (320 x 240 pixels)
Image Controls Touch screen LCD
Measurement
Temperature range –20°C to +120°C (–4˚F to +248˚F), Optional up to 350°C (662˚F)
Accuracy ±2ºC (±3.6ºF) or ±2% of reading
M
easurement modes
Spotmeters, Box areas,Isotherm, Difference temperature function,
Reference temperature
Humidity & insulation alarm Yes
Set-up controls
Mode selector, color palettes, configure info to be shown in image, local
adaptation of units, language, date, and time formats, image gallery, image
markers
M
easurement corrections
R
eflected ambient temperature correction
I
mage Storage
Digital storage functions Removable SD Memory Card
Image storage capacity 1000+ JPEG images
Image annotation Digital photo,Text (from list or Touch Screen), Voice and Sketch
La
ser Loc
atIR
™
Classification Class 2
Type Semiconductor AlGaInP Diode Laser: 1mW/635 nm (red)
Power Source
Battery type Rechargeable Lithium-Ion battery
Battery operating time 4 hours
Battery charging 2 bay charging system, 10-16 V input. Charging status indicated by LED's
AC operation AC adapter, 90-260 VAC input. 12 V output to camera
Voltage 11-16 VDC
Power saving Power management, automatic shut down and sleep mode after settable time
Environmental
Operating temperature range -15°C to +50°C (5°F to 122°F)
Storage temperature range -40°C to +70°C (-40°F to +158°F)
Humidity 10% to 95%, IEC 359
Water and dust resistant (encapsulation) IP 54, IEC 529
Shock 25G, IEC 68-2-29
Vibration 2G, IEC 68-2-6
Physical Characteristics
W
eight
0.88 k
g (1.94 lb.)
Size (L x W x H) 106 x 201 x 125 mm (4.2 x 7.9 x 4.9 in.), with built-in lens pointing forward
Color Titanium Grey
Tripod mounting 1/4" - 20
Interfaces
USB (c
able included)
Image tr
ansf
er t
o PC
Video output NTSC Video
Software
QuickReport™
Included
Rep
or
t
er™ 8.2
Optional
The Best in Infrared
www.goinfrared.com/B400
ThermaCAM® B400
NEW!
The most affordable, feature rich
infrared camera available!
From Left to right: USB mini for PC image download,4 pole audio for
voice annotation,NTSC video,USB-A for memory stick image transfer
