Acquisition Interface

3–8 IMAGING SOFTWARE OVERVIEW

6 Stop button: Stops the unit rotative arm movement.

7 Pre-shoot button: Performs a single scout image to validate the proper selection of the region of

interest.

8Ready Indicator LED:

 Green indicates the unit is ready to start acquisition

 Black indicates the unit is not ready to start acquisition

9 X-Ray Emission Indicator: Yellow indicates the x-ray emission status.

10 Exit button: Closes the Acquisition interface.

11 Selector button: Selects different acquisition setting options.

 Click Program to select examination type options

 Click Patient to select patient type parameters

 Click Parameters to select exposure parameter options
