Increasing Memory Capacity
Warning:
To avoid damaging the DIMM, do
not touch its contact edge.
11
Insert the DIMM into either of the sockets on the DIMM
adapter.
a)
Find the notch 1 on the side of the DIMM.
b)
With the notched end of the DIMM toward the right side of
the socket 2 , insert the DIMM, at an angle of
approximately 35 degrees, into the socket; then press it
firmly.
c)
Pivot the DIMM until it snaps into place.
If you have another DIMM to install, insert it into the other
socket in the same way.
2
1
1
2
2
1
35
Side View
Chapter 6. Installing and Removing Options 141
