51
Assembly and Installation
MAINTENANCE MANUAL
9. Apply axle oil lubricant on the inside surfaces
of both case halves, spider or cross, thrust
washers, side gears and differential pinions.
10.Placetheangecasehalfinabenchwiththe
ring gear teeth toward the TOP.
CAUTION
THE SIDE GEARS IN SOME DIFFEREN-
TIAL MODELS HAVE HUBS OF DIFFER-
ENT LENGTHS. INSTALL THE CORRECT
LENGTH SIDE GEAR INTO THE FLANGE
CASE HALF. DAMAGE TO COMPONENTS
CAN RESULT.
11. Install one thrust washer and side gear into
theangecasehalf.Figure5.22.
12. Install the spider or cross, differential pinions
andthrustwashersintotheangecasehalf.
Figure 5.23.
NOTE: is recommended that all parts are re-
assembled in the same position they were
prior to disassembly
13. Install the second side gear and thrust
washer over the spider and differential pin-
ions. Figure 5.24.
14. Place the plain half of the differential case over
theangehalfandgears.Rotatetheplainhalf
as needed to align the match marks. Figure
5.24 and Figure 5.25.
15. Install Dri-Loc® or equivalent fasteners into
the case halves. See Section 4.
Figure 5.22
Figure 5.24
Figure 5.25
SIDE GEAR
THRUST WASHER
FLANGE CASE HALF
SIDE GEAR
PLAIN CASE
HALF
THRUST WASHER
MATCH MARKS
PLAIN CASE
HALF
SPIDER,PINION AND
THRUST WASHERS
Figure 5.23
