9300 Mobile Computer
Reference Manual
5) Select 1. Update image now and press
to prepare for download.
6) In the Image Tool, it will show 9300 has been connected successfully.
Go to WINCE Image | Download, and select the desired image file (*.nb0).
It will take approximately 3 minutes before a message is displayed on the mobile
computer to indicate the OS upgrade is completed successfully. It will then perform
hardware reset on 9300 automatically.
Warning: Do not press any key on the mobile computer while upgrading OS image,
and make sure the power cord is connected.
Description
Enter USB Update Menu.
1. Launch OS
2. SD Update
〉3. USB Update
4. Show Version
USB U
p
date Menu
Description
Update image by USB.
Supported images:
Bootloader/OS/MicroP.
〉1. Update image now
2. BACK
CPT9300CE Bootloader Menu
