AUDIO

(CB)

(CR)

HDMI

Using external equipment

Connecting a DVD player

You can use the INPUT 1, INPUT 2, INPUT 3 (HDMI) or INPUT 4 (HDMI) terminals when connecting to a DVD

player and other audiovisual equipment.

NOTE

• When using a DVI-HDMI conversion adaptor, input the Audio Signal from the AUDIO terminal of INPUT 3.

DVD player

HDMI Cable (commercially available)

Component cable

(commercially available)

Audio cable

(commercially available)

When using component cable, select

“Component” for “Input Select” in the menu.

To watch an image from this input terminal, you

need to select the input source (see page 55) and

the input signal type (see page 46).

D53X_en_j.indd 56D53X_en_j.indd 56 2007-7-31 8:31:302007-7-31 8:31:30
