Specifications
Parts Specifications
CPU Pentium III Processor 800MHz
Secondary cache 256KB(Integrated with CPU)
ROM Including system BIOS, VGA BIOS and Plug&Play compliant
BIOS
RAM System SDRAM 128MB (expandable to 256MB)
Video 8MB (Shared with system RAM)
Display Panel Active Matrix (TFT) color LCD
Video controller SiS 630
Keyboard IBM compatible keyboard
Pointing device Glide pad (touch-sensitive control pad with 2 buttons )
Drive Hard disk 20GB(IDE interface)
CD-R/RW Reading:max. 24 x, Writing: max. 8 x, Re-writing:max. 4 x
Floppy disk 3.5", 1.44MB/720KB
PC card slot Type II
×
2 (PCMCIA 2.1 compliant) or Type III
×
1,CardBus
compliant
Audio system Monaural microphone, stereo speakers, sound system compliant with
AC97
I/O ports Audio Audio input jack(stereo), Audio output jack(stereo, S/PDIF
compliant), external microphone jack(monaural)
Video External monitor port
Others Parallel port, RS-232C serial port, keyboard/mouse port, two
USB ports
Infrared IR port (IrDA:115Kbps/4Mbps, SHARP ASK:9600bps)
Modem (may not be available in some
countries)
Data: 56Kbps(receive), 33.6Kbps(send)
LAN 100BASE-TX/10BASE-T
Power AC adapter 100-240V, 50-60 Hz
Battery Rechargeable NiMH battery pack
Battery life Approximately xx hour
*battery life may vary depending on usage
Battery charging time Turned off/in Hibernation: about x hours
Turned on: about x hours
*charging time may vary depending on usage
Dimensions 310mm wide x 265.4mm deep x 45mm high
Weight About 3.6kg
Operating Temperature 50°F to 95°F (10°C to 35°C)
environment Humidity 20% to 80% (non-condensation)
- CAUTION: 1
- Notice for Users in Australia 2
- Safety Precautions 3
- Handling 4
- Charging 4
- Discharging 4
- About This Manual 6
- Manual Conventions 8
- Overview of Computer 11
- Quick Setup 14
- Setting up Windows Me 18
- Shutting Down the System 20
- Basic Operations 21
- Using the AC Adapter 22
- Resetting the System 23
- Using The Glide Pad 24
- Changing the Configuration 25
- Using The Keyboard 26
- Quick Start Buttons 27
- Automatic E-mail Receiver 28
- Using Floppy Disk Drive Unit 29
- Formatting a Floppy Disk 30
- Backing Up Data 30
- Using CD-RW Drive 31
- Removing a CD 32
- Writing Data to CD-R/RW 33
- Battery and Power Management 34
- Checking the Battery Level 35
- Charging the Battery Pack 36
- Initializing Battery Pack 36
- Replacing Battery Pack 36
- Power Management 38
- Disabling Power Management 40
- Peripherals 41
- Connecting a Printer 45
- Installing a Printer Driver 45
- External Monitor Port 46
- Display Cable 46
- Using Multiple Monitors 48
- Keyboard/Mouse 49
- Connecting Microphone 53
- USB Device 54
- Communication Functions 55
- To Telephone Line 57
- Modem Jack 57
- Core(may not be 59
- Network Hub 59
- LAN Jack 59
- Hardware Expansion 61
- Label Face 62
- Memory Module 64
- Lock Lever 64
- Keyboard Cover 64
- Projection Part 66
- Notched Part 66
- Security Features 69
- Windows Password 70
- Security Slot 71
- Setup Utility 73
- Using the Setup Utility 74
- Main menu 75
- Advanced menu 76
- Security menu 77
- Power menu 78
- Boot menu 79
- Exit menu 79
- Troubleshooting 81
- Trouble with Display 83
- Appendixes 91
- Traveling with the Computer 92
