TROUBLESHOOTING

Misfeed in the transport area C

Lift up the duplex conveyor lever and open the reversing unit.

Remove the misfed paper.

Return the duplex conveyor lever to its original position and close the side cover.

The message " Clear paper path." will be cleared and printing will be possible.

• When closing the side cover, press on around the handle.

• If the paper was torn, make sure that no torn pieces remain in the machine.

• If the message does not clear, check again to make sure that no pieces of paper remain.

Note
