English - 37 -
Screw Dimensions Wall Mounting
MODEL VESA
TO THE PRODUCT
MIN. / MAX. SCREW LENGTH
(A LENGTH)
LC-42LE760E
LC-42LE761E
LC-42LE761EN
LC-42LE761K
LC-42LE762E
LC-42LE762EN
200 x 200 (W X H)
M6 x 8 / M6 x 12
LC-50LE760E
LC-50LE761E
LC-50LE761EN
LC-50LE761K
LC-50LE762E
LC-50LE762EN
400 x 400 (W X H ) M6 x 8 / M6 x 12
Screw length = A+B
Screw
Cabinet
Wall mount angle
