Using a USB device

The TV provides you some functions using a USB

device. You can select which function to use after

inserting a USB device in the USB port, and the TV

starts the settings for each function.

USB usage

• Storage device for time shift

• USB media to enjoy photos, music and videos

Connecting a USB device

Connect a USB device to the TV as shown below.

NOTE

• Some USB devices may not work properly for this

function.

• Directly connect the USB storage device for time shift to

the USB port.

• Do not connect and disconnect a USB device from the

TV repeatedly.

Selecting USB usage

You need to select which function a USB device is

used for when the USB device is inserted in the USB

port.

1 Connect a USB device to one of the USB ports.

• The screen prompt pops up.

NOTE

• If a USB storage device is inserted during time shift

operation, a screen prompt will not pop up.

2 Select the function you want to use.

Press c/d, and then press ;.

USB media

Time shift

NOTE

• When you want to configure a software update, you

need to press > to close the window.

For time shift

You need to complete the following procedure to

use the USB storage device for time shift. After

selecting “Time shift”, the TV starts initializing the

USB storage device. Follow the screen prompt to

complete the setting.

1 Press c/d to select “Yes”, and then press ;.

• Reconfirm use of the USB storage device for time

shift.

NOTE

• The supplied USB memory is used for the operation

manual of this TV and may not be used for time shift.

• When you have inserted two or more USB storage

devices in the ports, an error message appears. Insert

only one USB storage device for time shift.

• You can also set the USB storage device to be used for

time shift in the “Device registration” menu (Page 50).

• At least 1 GB is required for a USB storage device for

time shift.

• A USB HDD cannot be used as a USB storage device

for time shift.

2 Press c/d to select “Yes”, and then press ;.

• The TV starts initializing the USB storage device.

• Delete the data in the USB storage device.

NOTE

• Do not disconnect the USB storage device when the TV

is recognizing the memory for time shift.

3 Select “OK”.

Press ;.

NOTE

• If an error message is displayed on the screen, follow

the screen prompts and remove the USB storage

device.

Go to Time shift on page 48.

For USB media

After selecting “USB media”, the TV switches to the

USB media.

Go to USB media/Home network on page 51.

NOTE

• Depending on the USB device, the TV may not be able

to recognise the contained data.

• Use only alphanumeric characters for naming files.

• File names over 80 characters (may vary depending on

the character set) may not be displayed.

• Do not disconnect a USB device or memory card from

the TV while transferring files, using the slide show

function, when a screen is switching to another or

before you exit “USB media” from the “INPUT” menu.

Disconnecting the USB device

When you disconnect the USB device, be sure to

the following steps.

For time shift

Go to “Menu” > “Setup” > “Option” > “Time shift

setting” > “Device removal”.

NOTE

• This menu item cannot be selected when a USB storage

device for time shift is not registered.

• The USB storage device registration for time shift is

cancelled in the following cases:

− When the USB storage device is removed.

− When another USB storage device is registered for

time shift; only one USB device can be registered for

time shift.

For USB media

1 Press B on the remote control unit.

• Display “USB media menu”.

2 Press a/b to select “USB device removal”, and

then press ;.

3 Press c/d to select “Yes”, and then press ;.

Other useful features
