CARE AND CLEANING

Disconnect the power supply cord before cleaning or leave the door open to inactivate the oven.

CLEAN THE OVEN AT REGULAR INTERVALS - Keep the oven clean and remove any food deposits, or it

could lead to deterioration of the surface. This could adversely affect the life of the appliance and possibly result

in a hazardous situation.

Exterior:

The outside may be cleaned with mild soap and warm water, wipe clean with a damp cloth. Avoid the use of

harsh abrasive cleaners. Keep the ventilation openings free of dust.

Door:

Wipe the door and window on both sides, the door seals and adjacent parts frequently with a damp cloth to

remove any spills or spatters. Do not use abrasive cleaners.

Touch Control Panel:

Wipe the panel with a cloth dampened slightly with water only.

Do not scrub or use any sort of chemical cleaners. Avoid the use of excess water.

Interior walls:

To clean the interior surfaces, wipe with a soft cloth and warm water. After use wipe the waveguide cover

in the oven with a soft damp cloth to remove any food splashes. Built-up splashes may overheat and begin

to smoke or catch fire. Do not remove the waveguide cover. DO NOT USE A COMMERCIAL OVEN

CLEANER, ABRASIVE OR HARSH CLEANERS AND SCOURING PADS ON ANY PART OF YOUR

MICROWAVE OVEN. NEVER SPRAY OVEN CLEANERS DIRECTLY ONTO ANY PART OF YOUR OVEN.

Avoid using excess water. After cleaning the oven, ensure any water is removed with a soft cloth.

Turntable/Roller Stay:

Wash with mild soapy water and dry thoroughly.

SERVICE CALL CHECK

Please check the following before calling for service:

1. Does the display light up? YES _______ NO _______

2. When the door is opened, does the oven lamp come on? YES _______ NO _______

3. Place one cup of water (approx. 250 ml) in a glass measure in the oven and close the door securely. Oven

lamp should go off if door is closed properly. Press the INSTANT COOK/START pad once.

A. Does the oven lamp come on? YES _______ NO _______

B. Does the cooling fan work? YES _______ NO _______

(Put your hand over the rear ventilation openings.)

C. Does the turntable rotate? YES _______ NO _______

(The turntable can rotate clockwise or counterclockwise. This is quite normal.)

D. After one minute, did an audible signal sound and COOK

indicator go off? YES _______ NO _______

E. Is the water inside the oven hot? YES _______ NO _______

If “NO” is the answer to any of the above questions, please check your wall socket and the fuse in your meter

box.

If both the wall socket and the fuse are functioning properly, CONTACT YOUR NEAREST SERVICE CENTRE

APPROVED BY SHARP.

NOTE: 1. If time in the display is counting down rapidly, check Demonstration Mode. (See page 20 for detail.)

2. If you cook the food over 40 minutes on 100% power, the microwave power will be automatically

reduced to avoid overcooking.

SPECIFICATIONS

* When tested in accordance with AS/NZS 2895.1.2004

** This is the classification of ISM (Industrial, Scientific and Medical) equipment described in the International

Standard CISPR11.

AC Line Voltage Single phase 230-240V, 50Hz

AC Power Required 1.67 kW

Output Power 1200 W* (IEC test procedure)

Microwave Frequency 2450 MHz (Class B/Group 2)**

Outside Dimensions (WxHxD) 520mm x 310mm x 413mm

Depth with the door open 800mm

Cooking Uniformity Tur

ntable (ø320mm tray) system

Weight Approx. 16 kg

SCA/SCNA R398K(S) O/M,P22- 05.9.8, 10:12 AM24
