Video Driver Controls
Attaching Other Displays C - 23
C
To Enable Extended Mode:
1. Attach your external display to the external monitor port/HDMI-Out port, and turn it on.
2. Go to the Intel(R) HD Graphics Control Panel control panel and click Display >
Multiple Displays (sub-menu).
3. Click Extended from the Select Multiple Display Mode menu.
4. Click Apply, and OK to confirm the settings change.
Display Settings
Extended Desktop
You can have different
Colors, Screen Area
and Monitor Refresh
Rates for each display
device provided your
monitor can support
them.
You can drag the moni-
tor icons to match the
physical layout of your
displays. Icons and pro-
grams may also be
dragged between the
displays.
Figure C - 17
Display > Multiple
Displays (Extended)
Click the appropri-
ate monitor icon
and drag it to match
the physical ar-
rangement you
wish to use (e.g. the
secondary display
may be extended
left/right/above/be-
low the primary dis-
play).
Click Display Set-
tings to make any
adjustments re-
quired.
