The command examples shown on this page assume the following connection and ID number set

up.

PC ID number: 1 ID number: 2 ID number: 3 ID number: 4

IDST······A monitor receiving this command sets its own ID number in the parameter field.

Example: IDST0001

001 ←The ID number of this monitor is set to 1.

Note

After linking monitors, you can automatically assign ID numbers by using the IDST command with

the Repeater control (see “Repeater control” on page 42).

PC Set 1 Set 2 Set 3 Set 4

[Example]

If you connect monitors as shown above, and use the command “IDST001+”, ID numbers

will be set automatically, as shown below.

PC ID number: 1 ID number: 2 ID number: 3 ID number: 4

[Example]

IDST001+ ←ID setting command with repeater control

WAIT

001 ←ID = “OK” response from ID number=1

002 ←ID = “OK” response from ID number=2

003 ←ID = “OK” response from ID number=3

004 ←ID = “OK” response from ID number=4 (End)

PC Operation (Continued)
