Installing the Toner Cartridge and Drum Cartridge

Manually resetting the toner counter

When a new toner cartridge is installed, the toner counter is reset in Step 7 on

the previous page. The procedure below is normally not necessary; however,

it can be used in the event that you need to reset the toner counter manually.

1 Press and then or

repeatedly until the display at right

appears.

2 Press .

3 Press .

4 Press repeatedly to exit.

Display:

CLEAR: START KEY

LIFE

TONER COUNTER

3: CLR DRUM COUNT

1 2 ... 17 18 19 20 21 22 23 24 25 26 27 ... 160 161
