1 - 3 ADJUSTMENT

Group

Error code

Machine status

Reference

Other service calls

Service call from the

laser optical

Service call from the finisher

Finisher related service call

Service call from the others

C94

C99

CA1

CA2

CA3

CA4

CA5

CA6

CA9

CAA

CAB

CAC

CAD

CAE

CAF

CD0

CB1

CB2

CB3

CB4

CB5

CB6

CB7

CB8

CB9

CBA

CBB

CBC

CBD

CBE

CBF

CC0

CC1

CC2

CC4

CC5

CC6

C92

C94

C99

F10

M-CPU is abnormal

PFC microcomputer is abnormal

Polygonal motor is abnormal

HSYNC is abnormal

Secondary scanning rough adjustment error

Primary scanning counter load error

Laser power adjustment error

Laser PWM calibration error

Image data transfer malfunction from SYS board

Secondary scanning fine adjustment error

Secondary scanning inter-page compensation error

Primary scanning dot adjustment error

Primary scanning tap adjustment error

Primary scanning tap amount measurement error

Primary scanning inter-page compensation error

Laser initialize time-out error

Tra n sp o r t mo to r i s a bn o r ma l

Exit motor is abnormal

Tra y e leva ti o n mo t or is ab no r m al

Alignment motor is abnormal

Staple motor is abnormal

Staple unit shift motor is abnormal

Stacking sensor is abnormal

Backup RAM data is abnormal

Saddle thrust motor is abnormal

Saddle front staple motor is abnormal

Saddle inner staple motor is abnormal

Saddle alignment motor is abnormal

Saddle guide motor is abnormal

Saddle fold motor is abnormal

Saddle positioning plate motor is abnormal

Sensor connector connection error

Microswitch error

Communications error between finisher saddle

Swing motor is abnormal

Horizontal registration motor is abnormal

Punch motor is abnormal

Power abnormality interrupt error

MCPU is abnormal

PFC microcomputer is abnormal

HDD formatting error

4.8

4.8

4.8

4.8

4.8

4.8

4.8

4.8

4.8

4.8

4.8

4.8

4.8

4.8

4.8

4.8

4.9

4.9

4.9

4.9

4.9

4.9

4.9

4.9

4.9

4.9

4.9

4.9

4.9

4.9

4.9

4.7

4.7

4.7

4.7

1 2 3 4

1. ADJUSTMENT 1
ADJUSTMENT 1 - 4 4
