Optional Settings
194
PRIORITY setting will now appear. Use this setting to select the source from
which you want paper to be drawn in the event that the “1ST PRIORITY”
source runs out of paper. If you wish to have the incoming fax received to
memory in this case, select “NONE”. When you have completed the selection,
press .
FO-DC600: If the machine has two paper cassettes and Option Setting 31
(Seperate Mode) is turned off, and if you did not select “NONE” for the “2ND
PRIORITY” setting, the “3RD PRIORITY” setting will appear. Use this to
select the source from which you want paper to be drawn in the event that
both the ”1ST PRIORITY” and the “2ND PRIORITY” sources run out of paper,
or select “NONE” to have the fax received to memory. When you have
completed the selection, press .
♦ Initial setting: AUTO SELECTION
Setting 17: RETRANSMISSION TIMES
This sets the number of times the fax will reattempt a memory transmission
which has been interrupted by a line error or power failure. Enter any 2-digit
number from to , or enter to turn off the function.
♦ Initial setting: 10
Setting 18: RETRANSMISSION INTERVAL
You can select the number of minutes the fax waits between each memory
retransmission attempt. Enter for 1 minute, for 2 minutes,
etc., up to a maximum of 15 minutes. If you do not want the fax to wait
between attempts, enter .
♦ Initial setting: 02
Setting 19: POWER SAVE MODE
To conserve power, you can have the laser printer heater in the machine turn
off when not in use. When this is done, the heater will turn on automatically
when you receive a document (there will be a slight delay before printing while
the heater warms up) and turn off when printing is completed. Select ON to
turn on the function or OFF to turn off the function. Press or to
make the selection and then press .
♦ Initial setting: ON
START/
ENTER
START/
ENTER
0
1 1
4
0 0
0
1
0
2
0 0
START/
ENTER
