Basic Operation
Collate Copying
The machine can collate at the same time as it copies.
You can use the Collate copy function for tasks such as those shown below.
Scan multiple originals and deliver complete sets of copies as
required according to page number.
The procedure for using collate copying is explained below.
1 Press the Function Menu key. Function Menu appears.
2 Press the U or V key to select [Collate].
3 Press the OK key. Collate appears.
4 Press the U or V key to select [Off] or [On].
5 Press the OK key. Completed. is displayed and the
screen returns to the basic screen.
6 Use the numeric keys to enter the number of copies, and
press the Start key Copying begins.
3
2
1
3
2
1
3
2
1
3
2
1
Original Copy
Function Menu:
a
b
*********************
2
Collate
T
3
Duplex
T
[ Exit ]
1
Paper Selection
T
Collate:
a
b
1
Off
*********************
2
*On
