SCAN HEAD LOCKING SWITCH

The scan head locking switch is under the original table. If the switch is locked ( ),

the unit will not operate. Unlock the switch ( ) as shown below.

To lock the scan head locking switch, hold up the catch in illustration and

turn the center knob counter-clockwise 90 degrees until you hear a click.

Lock Unlock

Grasp here and turn in

the direction of the arrow.
