6-6

CHAPTER6

USER MAINTENANCE

The document glass and the document cover (RADF transport belt)

must be kept clean to avoid dirty areas from being copied onto the

copies.

Document glass and document cover

Wipe the document glass and the document cover

(RADF transport belt) with a soft, clean cloth.

●

If necessary, dampen the cloth with water. Do not use thinner,

benzene, or similar volatile cleaning agents.

GENERAL INFORMATION

User maintenance
