Sending an Image Using a Rapid Key
93
3. Network
Scanner
3
If the destination is an e-mail
destination and you wish to enter a
message, your name, or your return e-
mail address, or select the file format
for the document, press .
(If the destination is an FTP or Desktop
destination, or if you wish to use the e-
mail settings that were stored in the
Speed Dial number and do not need to
enter a message, go directly to Step 6.)
4
Press to select the option you want to change, and then press
. Change the selected option as follows:
• FROM
Enter your name, press , enter your e-mail address, and press .
• FILE FORMAT
Press to select the desired combination of file format (TIFF or PDF)
and compression (G3, G4 or NO COMPRESSION), and then press .
• MESSAGE
Use the letter entry keys to enter a message (maximum of 256 characters).
A line break can be entered by pressing . When finished, press .
5
When you have finished changing the
options, press or to select
START SCANNING.
6
Press to begin scanning and transmission.
START/
ENTER
START/
ENTER
START/
ENTER
START/
ENTER
START/
ENTER
START/
ENTER
1:START SCANNING
2:FROM
XXX
3:FILE FORMAT
XXX
4:MESSAGE
NO MESSAGE
1:START SCANNING
2:FROM
XXX
3:FILE FORMAT
XXX
4:MESSAGE
NO MESSAGE
all.book Page 93 Thursday, May 13, 2004 8:51 AM
