Entering and Using Programs
161
6. Special
Functions
14
Enter the mailbox number (2 digits). (Go directly to Step 15 if the
receiving machine does not have mailboxes.)
15
Press .
16
Dial the receiving machine using one of the following methods:
• Press a Rapid Key.
• Press and enter a Speed Dial number (if you enter less than 3
digits, press to complete the entry).
• Enter a full fax number with the numeric keys.
17
Press .
18
Press and/or to adjust the resolution and contrast if
desired, and then press .
19
If you want the document to be sent through memory, press .
If you want the document to be sent directly from the feeder, press
. (This is not possible if you included a timer setting.)
20
Press repeatedly until you return to the date and time display.
START/
ENTER
SPEED DIAL
START/
ENTER
START/
ENTER
RESOLUTION
CONTRAST
START/
ENTER
START/
ENTER
DOCUMENT
M/?
STOP
Confidential transmission
(Continued from
Initial procedure
.)
.
all.bookPage161Wednesday,December18,20028:17AM
