4. Pull out the paper tray [E] and remove the foam block [F], tape, and silica
gel [G].
5. Open the platen cover and remove the optics lock pins [H].
6. Remove the left scale [I] (2 screws) and the scanner lock plates [J].
NOTE: Save the lock pins [H] and lock plates [D and J] for future use.
[G]
[E]
[F]
[I]
[J]
[H]
1 December 1990
3-5
